• Glass, solar absorbing, tinted
• Grille guard screen, insect protection (mounted behind grille)
• Antenna, fixed mast
• Spare tire delete (STD)
• Wheel, spare delete
• Door handles, Black
• Grille, base, molded in color, Black
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted (STD)
• Front fender extension, painted body color
• Lamps, cargo area, cab mounted with switch on center switch bank
• Assist steps
• Lamps, Smoked Amber roof marker
• Headlamps, halogen projector-beam
• Bumper, front, Black
• Paint, solid
• Electrical Provisions, rear of cab, upfitter, body builder wiring: includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
• Tires, rear 225/70R19.5G traction blackwall Goodyear: Max Axle Load: 15,000 lb.
• Black
• Lamps, rear, LED stop/turn and license plate, with incandescent backup lamps
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted: (STD)
• Provision for cab roof-mounted lamp/beacon: provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
• Tires, front 225/70R19.5G traction blackwall Goodyear: Max Axle Load: 7,940 lb.
• Auxiliary harness, 3' for headlamps and turn signals
• Tail lamp wiring harness provisions: includes wiring for standard left and right taillamps, separate 8 feet of extra cable wiring for left and right body-mounted tail lights
• License plate kit, front
• Paint Scheme, Style 1
• Spare tire delete: (STD)
• Mirrors, outside, black, heated power-adjustable, high-visibility vertical camper-style, and lower convex spotter glass, manual-folding.: Convex glass is not heated and not power adjustable. 102", Wide Load

• Visors, driver and front passenger, vinyl
• Seat trim, Vinyl
• Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display.)
• Speedometer, miles/kilometers
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Cruise control, steering wheel-mounted
• Door locks, power
• Air conditioning, single-zone
• Assist handle, front passenger and driver on A-pillars
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
• Steering column, manual Tilt-Wheel
• Seats, front 40/20/40 split-bench, 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
• Mirror, inside rearview manual day/night
• Seat Belt, Black
• Dark Ash seats with Jet Black interior accents, Vinyl seat trim
• Back-up alarm calibration: This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
• Power outlet, 110-volt AC
• Key system, 2 spare keys
• Label, fasten seat belts: "Fasten Seat Belts" reminder label on right hand and left hand front side door glass
• Remote Keyless Entry
• Defogger, rear-window electric
• Seats, front 40/20/40 split-bench, 3-passenger:
  • driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar.
  • (STD)
• Windows, power with driver express up and down and express down on all other windows

• Front suspension, 7,500 lb. (3,402 kg) multi-leaf, includes shock absorbers
• Emissions, 50 state certification
• Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
• Axle, Open rear axle, non-locking rear
• Capped Fuel Fill
• Steering, power (Bosch S2 8014 Plus)
• Fuel tank, rear only, 40 gallon mounted between frame side rails and behind rear axle
• Emissions, USA 50 State certified
• Incomplete vehicle
• Fuel, diesel B20
• Axle lubricant, rear, synthetic oil EmGard FE -75W-90
• Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
• Rear axle, 4.30 ratio Max road speed: 75 MPH
• Front axle, 7,500 lb., Dana Spicer 60-256, single-reduction, front driving
• Axle lubricant, front, synthetic oil EmGard FE-75W-90
• Exhaust brake
• Four wheel drive
• Trailer brake controller, integrated
• Batteries, heavy-duty dual 1300 cold-cranking amps: includes battery box mounted to left side under cab
• Additional fuel, 5 gallons
• 26,000 lb. GCWR (11,793 kg)
• DPF, diesel particulate filter, manual regeneration: customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
• Axle to End of Frame, 63"
• Battery, top post threaded, battery jump start stud: (located on battery box)
• Axle, limited slip, Dana Spicer Truetrac, torque proportioning limited slip
• Wheelbase, 189" (480.1 cm), 108" CA
• Exhaust system, rear exit
• Rear suspension, 15,500 lb. (7,031 kg) multi-leaf, vari-rate
• Rear axle, 4.30 ratio: Max road speed: 75 MPH
• Rear axle, 15,000 lb. (6,804 kg) Dana Spicer S16-130, single reduction
• 5500 HD Series
• Prop Shaft Guard, steel
• GVWR, 19,500 lb. (8845 kg)
• Skid Plate, steel, frame-mounted, protects the transfer case from the ground
• Alternator, 220 amps
• Recovery hooks, front, frame-mounted, black
• Front stabilizer bar

• Work Truck Preferred Equipment Group: includes standard equipment
• Snow Plow Prep Package: includes (UNL) auxiliary harness for headlamps and turn signals, (KW5) 220-amp alternator, forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon

• Daytime Running Lamps, with automatic exterior lamp control

• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Rear Vision Camera, display integrated into Radio (Shipped loose in cab for upfitter installation.)
• OnStar, delete
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• Horn, dual-note
• Backup alarm: (Includes (SFW) SEO Calibration for backup alarm.

• StabiliTrak, Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
• Brake, parking, driveline park brake system
• Traction control

Snow Plow Prep Package

• DriveType
• DriveType: Four Wheel Drive
• Fuel Economy
• City: 0
• Hwy: 0
• Combined: 0
• Fuel System
• Fuel System: Direct Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 40 gal
• Fuel Type
• Fuel Type: Diesel Fuel
• Horse Power
• Horse Power: 350
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
